詳細介紹
主要規格
| 項目/Item | 型號/Type | YK3116A |
| 工件直徑 Maximum diameter of workpiece (mm) | 160 | |
| 切削模數 Maximum cutting modulus | 3 | |
| 軸向移動距離 Axial travel distance (mm) | 300 | |
| 徑向移動距離 Radial travel distance (mm) | 170 | |
| 滾刀外徑 Maximum outside diameter of hob (mm) | 80 | |
| 滾刀長度 Maximum hob length (mm) | 100 | |
| 竄刀范圍 Cutting range (mm) | 100 | |
| 滾刀轉速(r/min) Hob speed (r/min) | 200-2200 | |
| 工作臺轉速(r/min) Maximum working table speed (r/min) | 500 | |
| 主電機輸岀功率(KW) Main motor output power (KW) | 3/4.4 | |
| 總使用電力(KVA) Total electricity consumption (KVA) | 12 | |
| 機床重量(T) Machine weight (T) | 4.5 | |
標準附件(干濕通用)
Standard accessories(Wet and dry, manual/automatic loading and unloading)
● 油壓潤滑油裝置
○ Oil pressure lubricating device
● 電器柜內空調
○ Air conditioner in electrical cabinet
● 防濺護罩
○ Splash guard
● 滾刀刀桿
○ Hob cutter bar
● 工件夾緊裝置
○ Workpiece clamping device
可選附件
Optional accessories
● 排屑機
○ Chip removal machine
● 二次對刀裝置
○ Secondary tool setting device
● 粗去毛刺裝置
○ Coarse deburring device
● 油霧處理裝置
○ Oil mist treatment unit
● 液壓油缸夾緊裝置
○ Hydraulic cylinder clamping device
● 自動上下料裝置
○ Automatic loading and unloading device
